Name: Series 4000 Server Cabinets
Brand: Electron Metal

Series 4000 Server Cabinets

Product form

Fully Welded 14-Gauge Steel Server Cabinets 24RU to 48RU,
Configurable Depth, 3,000 lb Load Capacity

The Series 4000 is a fully welded, EIA-310-compliant server cabinet manufactured in Quebec from 14-gauge cold rolled steel. Nine standard configurations span 24RU to 48RU with depths from 36″ to 48″, and the platform supports a static load capacity of 3,000 lbs across every model. CSA-certified (C22.2 No. 70950-1) and designed to TIA-942 data center standards, the Series 4000 ships fully assembled with a 10-year structural warranty.

Downloads & Links

Product Resources

Product Drawings

Part Details

Downloads

Division 27 Download

Links

Request an Account to view pricing and availability

Series 4000 — Server Cabinets

Product Specifications

All dimensions in inches (W × H × D). Fully welded 14 ga. cold rolled steel construction. 3,000 lbs load capacity with 10-year warranty.

Filter by Rack Units

9 configurations

Scale	Model	Rack Units	Overall Dim. W × H × D	Usable Dim. W × RU × D	Resources

Electron Metal

Product Details

DESCRIPTION

Fully Welded 14-Gauge Steel Server Cabinets 24RU to 48RU, Configurable Depth, 3,000 lb Load Capacity

The Series 4000 is a fully welded, EIA-310-compliant server cabinet manufactured in Laval, Quebec from 14-gauge cold rolled steel. Nine standard configurations span 24RU to 48RU with depths from 36″ to 48″, and the platform supports a static load capacity of 3,000 lbs across every model. CSA-certified (C22.2 No. 70950-1) and designed to TIA-942 data center standards, the Series 4000 ships fully assembled with a 10-year structural warranty.

Six door types, adjustable-depth 19″ cage-nut mounting rails, a universal accessory channel, and configurable top-cover ventilation allow the cabinet to adapt as rack density, airflow requirements, and cable management needs evolve without replacing the enclosure. Depths of 30″ and custom dimensions are available on request.

KEY FEATURES

Fully Welded 14-Gauge Frame	One-piece cold rolled steel frame with no bolt-together joints. Fully welded construction eliminates rack flex under load and maintains structural integrity through repeated equipment changes. Cabinet weights range from ~184 lbs (24RU) to ~357 lbs (48RU). 10-year structural warranty.
19″ EIA-310 Mounting Rails (4)	Two pairs of adjustable-depth cage-nut mounting rails (2.25″ wide) with RU markings and integrated cable pass-throughs. Front-to-rear depth adjustable to accommodate varying equipment depths. 50 cage nuts (10-32) and 50 truss head screws (10-32 × 5/8″) shipped loose.
Perforated Front Door	Single-swing perforated steel door with lockable swing handle. Perforation pattern supports front-to-rear airflow for rack-mounted equipment cooling.
Split Perforated Rear Doors	Two-panel split rear doors (left-hand and right-hand) with lockable swing handles. Split configuration allows rear access in constrained aisle environments without full-swing clearance.
Lockable Side Panels	Quick-release side panels with integrated locks. Removable for adjacent-cabinet access during installation or maintenance, securable for production environments.
Universal Accessory Channel / VCM	Full-height UAC/VCM channel (6″ wide) supporting PDU mounting, vertical cable management accessories, and other toolless-mount components. Runs the full usable height of the cabinet.
Top Cover with Fan Cutouts	Solid steel top cover with four 6″ fan cutouts (cover plates included) plus two top front cover plates. Supports top-of-rack exhaust fan installation and cable entry routing.
Levelling Feet	Four industrial levelling feet (1/2″-13 thread, steel base) for floor alignment on uneven surfaces.
3,000 lb Static Load Capacity	Rated for 3,000 lbs of static equipment load across all nine configurations. The 42RU × 42″D model (CB4KSV-214242) additionally supports 2,000 lbs with optional casters.
CSA Certification	Every configuration certified to CSA C22.2 No. 70950-1. Designed to EIA/ECA-310-E rack mounting standard and TIA-942 data center infrastructure standards.

Door Alternatives	Solid steel, louvered, acrylic (viewing window), and custom door configurations available for front and rear positions. Door selection determines the airflow-vs-security balance for each deployment environment.
Side Panel Alternatives	Perforated, louvered, and custom side panels available as alternatives to standard solid panels. Perforated panels support supplemental side-entry airflow in high-density or non-containment deployments.
Depth Configurations	Standard depths: 36″, 42″, 48″ (see Available Sizes table). Also available in 30″ depth for space-constrained environments. Custom depths engineered on request.
Caster Option	Optional caster plates with 3″ (76 mm) pivoting casters. Load capacity reduces to 2,000 lbs when caster-mounted. Documented on the 42RU × 42″D configuration (CB4KSV-214242); contact sales for other models.
Thermal Management	Optional top-mount exhaust fans (four 6″ positions pre-cut), hot air chimney configuration via removable rear top cover plate, and compatibility with Electron Metal aisle containment systems.
Power Distribution	Universal accessory channel accepts vertical-mount PDUs. Compatible with Electron Metal power distribution accessories for metered, switched, and basic power configurations.
Finish Colors	Textured powder coat in Black (-BK), White (-WH), or Grey (-GY). Custom colors available on request.

Electron Metal

SPECIFICATIONS

Frame Material	14-gauge cold rolled steel, fully welded
Static Load Capacity	3,000 lbs (all configurations)
Load Capacity with Casters	2,000 lbs (documented on CB4KSV-214242; casters optional)
Finish	Textured powder coat
Available Colors	Black (-BK), White (-WH), Grey (-GY); custom on request
Warranty	10-year structural warranty
Assembly	Ships fully assembled; no on-site frame construction required

Mounting Standard	19″ EIA/ECA-310-E compliant
Mounting Rails	4 adjustable-depth cage-nut rails, 2.25″ wide, with RU markings
Rail Hardware (included)	50 cage nuts (10-32) + 50 truss head screws (10-32 × 5/8″)
Front Door (standard)	Single-swing perforated, lockable swing handle
Rear Doors (standard)	Split perforated (LH + RH), lockable swing handles
Side Panels (standard)	Solid with integrated locks, quick-release
Floor Mounting	4 levelling feet (1/2″-13 thread, steel base)

Universal Accessory Channel / VCM	1 full-height channel (6″ wide) for PDU and accessory mounting
Top Cable Entry	Multiple entry points via top cover and two removable 6″ × 12″ cover plates
Top Fan Positions	4 × 6″ fan cutouts (pre-cut in top cover, with cover plates)
Chimney Option	Removable rear top cover plate enables directed hot-air exhaust
Containment Compatibility	Compatible with Electron Metal hot aisle and cold aisle containment systems

Safety Certification	CSA C22.2 No. 70950-1 (all 9 configurations)
Rack Standard	EIA/ECA-310-E (19″ equipment mounting)
Designed To	TIA-942 data center infrastructure standards
Manufacturing Origin	Designed and manufactured in Laval, Quebec, Canada
